Description Main Range Acti9 Product or component type Comb busbar Mounting mode Horizontal Accessory / separate part category Connection accessory Lines description 3L N Total number of 18 mm modules 24 Standards EN/IEC 61439-1 Complementary Number of ways 6 ways N 3 L Distribution type N L1 L2 L3 Poles configuration for 1 way 1 x 3P N 1 x 4P Connection pitch 18 Mm Connector type Tooth Distance between way 72 Mm Marking N L1 L2 L3 Insulation Insulated Device presentation Cuttable [Ie] rated operational current 100 A at 40 °C [Ue] rated operational voltage 415 V AC [Ui] rated insulation voltage 500 V AC conforming to IEC 61439-2 Mounting location Top or bottom on tunnel type terminals Top or bottom on double terminal 9 mm pitches 48 Width 430 Mm Colour White (RAL 9003) Range compatibility Acti9 Acti9 iC60 Acti9 Acti9 iK60 Acti9 Acti9 iID Acti9 Acti9 iID K Acti9 Acti9 iSW Acti9 Acti9 iSW-NA Multi9 Multi9 C60 Environment Fire resistance 960 °C ( 30 s ) conforming to IEC 60695-2-1 Pollution degree 3 conforming to IEC 60947-7-1 IP degree of protection IP20 with end-pieces and tooth covers
